01
CNC Milling
3-axis vertical milling for prismatic and complex-profile components.
Up to 1050 × 610 × 610 mm
Capability
Machines, envelopes and what we can hold.
Four CNC machining and turning centres under Mitsubishi and Fanuc control, supported by in-house programming, fixturing and metrology.
- 3-axis VMC × 3
- CNC turning × 1
- 8000 RPM · BT-40
- 24-tool ATC
- Mitsubishi / Fanuc
Machining centres
BFW Chakra BMV 60+ TC24
Large 3-axis VMC
- Work envelope
- 1050 × 610 × 610 mm
- Spindle / tooling
- 8000 RPM · BT-40 · 24-tool ATC
- Control
- Mitsubishi
- Repeatability
- 0.012 mm
- Positioning
- 0.016 mm
BFW XTRON 544 (×2)
Compact 3-axis VMC
- Work envelope
- 500 × 400 × 400 mm
- Spindle / tooling
- 8000 RPM · BT-40 · 24-tool ATC
- Control
- Mitsubishi / Fanuc
- Repeatability
- 0.007 mm
- Positioning
- 0.010 mm
BFW Neo+ Turning Centre
CNC turning
- Work envelope
- Max turning Ø 300 mm
- Spindle / tooling
- 6000 RPM · A2-6 spindle
- Control
- Fanuc
- Repeatability
- 0.005 mm
- Positioning
- 0.007 mm
Mitsubishi and Fanuc CNC control across the fleet · 24-tool ATC on both VMC types · 8000 RPM BT-40 milling spindles · 6000 RPM A2-6 turning spindle
Process scope
Six processes, one documented chain of custody.
02
CNC Turning
Shafts, bushes, flanges and cylindrical parts up to Ø300 mm.
A2-6 spindle · 6000 RPM
03
Hole-Making
Drilling, tapping, boring, counter-boring and reaming to tight positional tolerance.
Positional tolerance controlled
04
Finishing
Deburring, bench finishing, part marking and Helicoil thread-insert fitment.
In-house bench
05
Inspection
First Article, in-process and final inspection with CMM and vision reporting.
5-axis CMM on site
06
Prototyping & Batch
First-off machining through to repeatable volume batches.
Qty 1 to low hundreds
Prototype to batch
First-off today. Repeatable batch next quarter.
We are sized for the work most large shops decline: single prototypes, first articles, and batches in the tens to low hundreds — with the same documented process either way.
- 01 Drawing review and manufacturability feedback before we quote.
- 02 Programming, fixture design and tooling selected per material.
- 03 First Article machined and measured on the CMM, report issued.
- 04 Batch released against the frozen process, with in-process checks.
Tell us the envelope, the material and the tightest feature.
We will confirm whether it fits the fleet, how we would fixture it, and what the inspection plan looks like.
